The New Endoscopic Visualization Platform that grows with you
Created to accelerate procedures and learning curves for improved patient outcome with advanced imaging, VISERA ELITE III is the future-proof endoscopic visualization platform with software upgrades and technology that allows you to focus on your procedures, while significantly reducing future costs.
- Multi-Specialty Video Processor
- All-in-One System
- Upgradable & Customizable
- Integration of 4K, 3D and IR in one system
- Allowing standardization for one imaging system across multiple ORs and specialties
- Activation of functionalities via software upgrade
- Customizable configurations to meet individual needs and budgets
- Large portfolio of procedure- specific scopes/cameras
| Power Supply | Rated voltage | 110–240 V AC; within ±10% |
|---|---|---|
| Rated frequency | 50/60 Hz; within ±1 Hz | |
| Rated input | Less than 170 VA | |
| Size | Dimensions (maximum)/td> | 390(W) x 198(H) x 500(D) mm |
| Weight | 12.1 kg | |
| Observation | Digital signal output | 12G-SDI (SMPTE ST 2082), 3G-SDI (SMPTE424M), HD-SDI (SMPTE292M) |
| Switching the recording output signal | This function allows you to switch the recording method of the video signal output to the recording device. · HD-SDI recording method · 3G-SDI recording method |
|
| Electronic zoom | Electronic magnification of endoscopic images is available. 4K camera head: 6 steps (×1.0, ×1.2, ×1.4, ×1.6, ×1.8, ×2.0) non 4K camera head: 3 steps (×1.0, ×1.2, ×1.5) |
|
| Observation mode | The optical-digital observation can be performed. The endoscope compatible with the optical-digital observation is required. |
|
| NBI observation mode, IR observation mode*, YE observation mode, 3D observation mode* | ||
| Documentation | Remote control | The following peripheral device can be controlled (specified models only). · Portable memory · Video recorder |
| Recording format | Standard image quality: TIFF Low image quality: JPEG | |
| Classification (Electromedical Equipment) | Degree of protection against electric shock | TYPE CF |
| Degree of protection against explosion | The product should be kept away from flammable gases. |
* IR/3D observation can be available by upgrading.
